Máy quét mã vạch để bàn 2D Datamax D8800

Model Number D8800
Performance Parameters
Đèn nguồn SXGA-W(Width1280*high1024) Ratio（5：4）
Hỗ trợ các chuẩn mã vạch 1D:EAN-8、EAN-13、EAN-13 2 add-on、EAN-13 5 add-on、ISSN、ISBN、UPC-A、UPC-E、Code11、Code 32、Code 39、Code 93、Code 128、Codabar、Industrial 2 of 5、Interleaved 2 of 5、Matrix 2 of 5、ISBT-128、GS1-128、GS1 DataBar（RSS14）、GS1 DataBar Limited、GS1 DataBar Expanded.
2D:PDF417、MicroPDF417、QR-code、MicroQR, Data Matrix、QR、Aztec.
Vùng quét 5mil(Code39) 1cm~15cm; UPC-13mil 1cm~33cm; 20mil(code39) 1cm~40cm; 20mil(QR Code) 1cm~28cm
Hệ điều hành hỗ trợ Linux、Android、Windows XP、7、8、10、MAC
Loại mã vạch 1d or 2d barcodes for Paper or Film；1d and 2d for screen ,like Phone tablets
Motion tolerance 3.8meters/second
Chế độ quét Automatic continuous reading mode
Ngôn ngữ hỗ trợ Support Multi-Language
Chỉnh sửa xuất mã vạch Support for adding suffixes
In tương phản 20%
Góc quét Turn angle ±360°, elevation angle ±60°, declination angle ±70°
Tính năng khác Led: Red and blue bi-color indicator: red light reading code, blue light power indicator.
Beeper: Startup prompts, reading tips.
Keys (touch keys): Key Switch and 2d barcodes.
Kết nối USB(Drive - Free)、RS232
Physical Parameters
Dimensions 119mm*135mm*166mm
Weight 390g
Material ABS+PC
Cable Length 180CM(±3CM)
Environmental Parameters
Operating Temperature -20℃~55℃
Storage Temperature -20℃~60℃
Relative Humidity 5%~95% RH(non-condensing/non-freezing)
Shock Resistance: Withstands three times1 . 5 meters drops to concrete
Waterproof and Dustproof IP54 standard
Ambient Ligh 0-70000LUX
Electrical Parameters
Working Voltage DC5V
Power USB Interface: Standby Power 0.2mA/1W; Operating Power 0.33mA/1.65W
Maximun Operating Power 0.481mA/2.405W.
RS232 Interface: Standby Power 0.2mA/1W; Operating Power 0.33mA/1.65W;
Maximun Operating Power 0.484mA/2.42W
